Parker PL-10 Series Portable Magnetic Coils

Parker PL-10 Portable Coils are designed for magnetic particle inspection of ferrous metal parts. The new coils allow for the use of either dry powder or wet fluorescent inspection media and may be used for demagnetizing as well.

The coils are molded in a tough black polyurethane material and come equipped with a foot switch and 10′ yellow neoprene power cord. The sealed electrical connection box has a 2″ × 4.5″ flat base allowing the coil to stand in a vertical position.

The coils are designed for a 50% duty cycle, and are equipped with thermal overload protection. Both the PL-10 and the PL-8 operate from a standard 115 VAC, 60 Hz power source. The PL10S and PL8S operate from a 230VAC, 50-60 Hz power source.

PL-10 Magnetizing Coil

The Parker PL-10 Portable Magnetizing Coil (9 7/8″ inside diameter) is designed for magnetic particle inspection of ferrous metal parts. The coil allows for the use of either dry powder or wet fluorescent inspection media and may be used for demagnetizing as well.

The coil is molded in a tough black polyurethane material and comes equipped with the standard foot switch or a optional hand switch and 10′ power cord. The sealed electrical connection box has a 2″ x 5″ flat base allowing the coil to stand in a vertical position.

The coil is designed for a 50% duty cycle, and is equipped with thermal overload protection. The 115 VAC version operates from a standard 115 VAC, 60 Hz power source. The 230 VAC version operates from a 230VAC, 50-60 Hz power source.

230VAC model available with CE certification at an additional cost

A plastic carrying case is included.

PL-10PDC Magnetizing Coil

The Parker PL-10PDC Portable Magnetizing Coil (9 7/8″ inside diameter) is designed for magnetic particle inspection of ferrous metal parts. The coil allows for the use of either dry powder or wet fluorescent inspection media.

The coil is molded in a tough black polyurethane material and comes equipped with the standard foot switch or a optional hand switch and 10′ power cord. The sealed electrical connection box has a 2″ × 5″ flat base allowing the coil to stand in a vertical position.

The PDC version operates from a standard 115VAC input, but produces a powerful half wave rectified D.C. magnetic field.

A plastic carrying case is included.
